Premium RA38 SQB-1 Series

UNDER CABINET 30" - 36"

680 CFM

Product information

Models

RA3830SQB-1 (30")
RA3836SQB-1 (36")

Size

,

Speed

Control

Max CFM

,

QuietMode

Ductless/ Recirculating

Ducting

Filter

Light

ECO Mode

Exhaust

Collection

Type

Features

Description

KOBE Premium under cabinet range hood is equipped with 3-speed mechanical push button, 680 CFM internal blower, dishwasher-safe baffle filters, and LED lights. This hood is handcrafted with durable 18-gauge commercial grade stainless steel with seamless design. A truly elegant slim-design range hood perfect for taller cabinets.

Features & Benefits

SERIES RA38 SQB-1
QuietMode™ At 280 CFM for 30″ or 300 CFM for 36″, this unique feature allows the KOBE range hood to operate at a reduced sound level of 40 decibels (1.0 sone).
Blower Type Single Horizontal Squirrel Cage
Speed / Control 3-Speed / Mechanical Push Control
CFM / Sone For RA3830SQB-1 (30″)
280 / 1.0 / QuietMode™
450 / 2.2 / low
680 / 5.0 / High
For RA3836SQB-1 (36″)
300 / 1.0 / QuietMode™
440 / 2.0 / Low
750 / 5.6 / High
Exhaust Top: 6″ Round
Light The hood is equipped with 3W LED lights
Filters Dishwasher safe professional baffle filters allow for easy cleaning.
Attractive Appearance The body of the hood is concealed inside the cabinets, and all you see is a slim 2-3/4 inch trim.
Easy to Clean KOBE’s unique design, which includes easy to empty catch areas and smooth hood surface, lets you clean the fans without disassembling the hood.
Quality Parts are checked for defects and designed for trouble free long term use.
Sizes 30″ and 36″
Easy to Install Our special design makes installation fast and easy.
Color Commercial Grade Stainless Steel
Versatile Installation This versatile hood can be used for under cabinet or for wall mount style with the optional duct cover.
Optional Accessories Stainless Steel Back Splash:
30″ Stainless Steel Back Splash – Model No. SSP30
36″ Stainless Steel Back Splash – Model No. SSP36
