Premium IS23 SQB-1 Series

ISLAND 36" - 36"

720 CFM

IS23 SQB-1 Premium Series has been awarded the 2017 ADEX Platinum Award for Design Excellence.

Product information

Models

IS2336SQB-DC16-1 (36")
IS2336SQB-DC23-1 (36")
IS2336SQB-DC59-1 (36")

Size

Speed

Control

Max CFM

QuietMode

Ductless/ Recirculating

Ducting

Filter

Light

ECO Mode

Ceiling (Min)

Ceiling (Max)

Chimney Sizes

Fit Ceiling Height

, , , , , , ,

Type

Collection

Exhaust

Features

, ,

Description

KOBE Premium 36-inch island range hood is beautifully handcrafted with 18-gauge commercial grade stainless steel for long-lasting durability. It comes with a 720 CFM internal blower designed for high, yet quiet, performance. The QuietMode feature allows this range hood to operate its six speeds at a reduced sound level. It includes 3 minute delay shutoff and ECO Mode technology that turns on the hood automatically for 10 minutes every hour to remove unwanted air particles without having to turn it on or off manually. It also comes with dishwasher-safe baffle filters and LED lights. This item ships in multiple boxes.

Features & Benefits

SERIES IS23 SQB-1
QuietMode™ At 280 CFM, this unique feature allows the KOBE range hood to operate at a reduced sound level of 40 decibels (1.0 sone).
Blower Type Twin Vertical Turbine Impeller
Speed / Control 6-Speed / Electronic Button Control / Delay Shutoff -3-Minutes
CFM / Sone 280 / 1.0 / QuietMode™
350 / 1.4 / Speed 1
420 / 2.8 / Speed 2
510 / 3.5 / Speed 3
610 / 4.2 / Speed 4
720 / 4.5 / Speed 5
Exhaust Top: 6″ Round
Light The hood is equipped with 3W LED lights with 3-level lighting.
Filters Dishwasher safe professional baffle filters allow for easy cleaning.
Attractive Appearance The seamless curves and stylish appearance of the hood will compliment any kitchen
Time Delay Control The Time Delay System features a 3-minute delay shutoff
ECO Mode ECO Mode runs the fan on the QuietMode™ setting for 10 minutes every hour to remove excess moisture, microscopic particles and odors to promote a cleaner kitchen air quality.
Easy to Clean KOBE’s unique design, which includes easy to empty catch areas and smooth hood surface, lets you clean the fans without disassembling the hood.
Quality Parts are checked for defects and designed for trouble free long term use.
Sizes 36″
Easy to Install Our special design makes installation fast and easy.
Color Commercial Grade Stainless Steel
Duct Cover Model No.: IS23DC-16-1 (included in IS23 SQB-DC16-1 hood only)
Model No.: IS23DC-23-1 (included in IS23 SQB-DC23-1 hood only)
Model No.: IS23DC-59-1 (Included in IS23 SQB-DC59-1 hood only)
Ceiling Heights • With IS23DC-16-1 duct cover: it fits ceiling height 7-1/2 feet.
• With IS23DC-23-1 duct cover: it fits ceiling height 8 feet to 9-1/2 feet.
• With IS23DC-59-1 duct cover: it fits ceiling height 9 feet to 11 feet.

Available Documents

Manual PDF
Part List PDF
